Powered microphones generally have more power than your standard microphone so that's why they're favored when doing surveillance. As this microphone is a powered microphone, the microphone requires a power source. Plugging those in completes 25% of the process can't get much simpler than that.Ģ of 4: Next you'll be connecting your microphone to the cable. At that point, you've completed 1/4 of the procedure. The adapters will clip into the coaxial portions of the cable and lock in. The first frame you see is your normal BNC cable. These adapters will essentially be changing your coaxial tips to RCA male jacks.ġ of 4: This animated picture (to the right) should show you exactly what I mean about converting your BNC coaxial tips. The adapter I mentioned is an RCA to BNC connector (as seen below.) You'll need two at this point, one for each end of the BNC cable. Sounds fairly simple enough so far, right? I'll go through these with picture explanations so hopefully we can avoid losing anyone in this tutorial. The following are the required pieces: Powered microphone ( STS-240SMP), 2 x RCA adapters ( SRC-450), a DVR, desired length Siamese BNC Cable.
#Samsung samrtcam microphone install#
There are several different ways to install it, but we will be going over the BNC cable option. As you can see here, it has a microphone (STS-240SMP), power plug, and an RCA plug. The microphone that we currently sell is quite mainstream in the sense that most other vendors carry similar style microphones. In the case you want to plug in a speaker, you also have the "audio out " however, that's a story for another time. These ports are labeled "audio in" and can support the microphone feature as long as you have the know how.
If you have a SDS or SDH system, you'll see that you have 4 RCA ports on the back of the DVR labeled from 1 to 4. Because of this fact, most of us have turned to powered microphones since the DVR's actually do have sound ports in the back. At best, the IP cameras and baby monitors are the only ones with sound recording.
This post is about using a powered microphone and a BNC cable to enable sound recording on a Samsung DVR.Īs most of you who are reading this at the moment will know, Samsung no longer has any microphone-embedded security cameras any more. I briefly went over a few ways to connect a powered microphone to the Samsung DVR's in the previous post, but even I found it to be a bit confusing with all the words and options. Connecting Your Microphone to your Samsung DVR
